APPLICATIONS
Coffee machines – decalcification
Deep fat fryer – oil change
Air conditioning – filter change, bleaching
Vacuum cleaner – filter cleaning
Motorised equipment – preventative maintenance, lubrication, belt
change
Petrol/Diesel engine generator – engine service
Central heating – gas appliance inspection
Inspection/cleaning interval reminder – washrooms, kitchens
Equipment calibration interval reminder
Electrical safety check interval reminder
CONNECTIONS
OPERATION
The smart indicator operates like a standard neon indicator, giving visible status
indication for the appliance or application. Normal operation will show continuous
Green LED illumination (contact sales for other colours).
When the accrued usage time exceeds the factory-set time limit, the LED illumination
changes colour to Red (contact sales for other colours) and starts to flash on/off to
attract user attention. The indicator will continue to flash on subsequent appliance use,
until the maintenance operation is carried out and the reset procedure followed.
To reset the indicator after maintenance operations are completed, simply link terminal
3 to terminal 4 while the indicator is powered. This could be a key-operated switch or a
service button within the appliance.
The service interval time is factory programmed, and can be any time period from as
little as one minute, up to tens of years.
PART NUMBER
1432AL
Specify Terminal Type:
C, H, T, X
Live
Reset Switch
Neutral
Specify Model Code:
Specify Supply Voltage:
Specify LED Colour:
Specify Time Setting:
1432AL
230Vac, 115Vac, 48Vdc, 48Vac, 24Vdc, 24Vac, 12Vdc,
12Vac
Green/Red, Blue/Red
Time interval between 1 minute and 10 years.
Specify the required time in minutes, hours, days,
weeks or months.
tel: +44 (0)20 8979 3232 ? Arcolectric ? email: info@arcoswitch.co.uk
91
